Safelift WREP system

We would like to introduce our Safelift WREP system for protection of Wire Rope slings when used with angular steel objects.
This product reduces wear of the wire rope slings and also prevents damage to the object being lifted as it helps reduce direct metal to metal contact and friction.

Please feel free to contact us if you have any questions or need any further information.

Tiger Manual Winch SF-2200 INDUSTRIAL

Sf 2200 Industrial Winch

  • 2200 lb/1000kg lifting & 4400lb/2000kg pulling capacity
  • Gears and brake are fully covered to prevent dust, dirt and rain contamination
  • Ratchet handle permits reciprocating handle movement in both directions for lifting and lowering loads
  • Very low operator effort is required for easy operation
  • Positive load-actuated brake can hold the load in any position
  • Ratchet handle accommodates installation in cramped locations
  • Operating temperature -40°C to +80°C (temperature range of -60°C to +80°C available as an option)

Certification

Each unit comes fully certified with a test certificate or an EC Declaration of Conformity stating compliance with the essential health and safety requirements of the Machinery Directive 2006/42/EC.



Due to our policy of continual product development, dimensions, weights and specifications may change without prior notice. Please check with us when ordering.

Certification

Each unit comes fully certified with a test certificate or an EC Declaration of Conformity stating compliance with the essential health and safety requirements of the Machinery Directive 2006/42/EC.



Due to our policy of continual product development, dimensions, weights and specifications may change without prior notice. Please check with us when ordering.

Data Table

Product Code Pulling Capacity (lbs/kg) Lifting Capacity (First Layer) Lifting Capacity (Last Layer) Hand Force Required (kg) Gear Ratio Hub Diameter (mm) Handle Length (mm) Unit Weight (with handle) (kg) Unit Weight (with loop) Cable Diameter (mm/inch) Cable Storage Cap. (m) Technical Drawing
SF-2200 4400/2000 2200/1000 10 22.2:1 Ø80 300 17.5 Ø8.0/Ø5/Ø16 25

TIGER BHW BRAKE HAND WINCH

The original brake hand winch

The Tiger Brake Winch is a high quality multi-purpose winch used for a wide variety of lifting and hoisting applications. The automatic brake ensures the load remains suspended when the crank is released and avoids unchecked descent of the load; there is no freewheeling making the hand winch extremely safe to operate. All the mechanical components are enclosed for protection against dust, dirt and rain contamination. This equipment has a lifting capacity ranging from 800lbs to 2600lbs. The BHW is compact and lightweight yet rugged and durable.

These units meet and exceed all the requirements within BS EN 13157: 2004+A1:2009.

Corrosion Resistant Option available

Noiseless 1200lb model available

Dual handle pinion shaft option available – allows handle to be fitted on both sides

BHW 1200
Bhw Strap

  • High quality multi-purpose winch
  • Automatic load-actuated brake can hold the load in any position
  • Compact, light-weight and rugged construction
  • Gears and brakes fully covered to prevent dust, dirt and rain contamination
  • Heat treated gears
  • Very low operator effort required for easy operation
  • Dual handle pinion shaft option available on all models, allows handle to be fitted on both sides
  • Universal mounting plate
  • Available as 800lb, 1200lb, 1800lb and 2600lb models
  • For cable and strap
  • Finished in high quality powder coat paint offering excellent corrosion protection
  • Fully corrosion protected versions available
  • Noiseless 1200lb model available
  • 3D Drawings available on full range for project planning
  • Operating temperature -40°C to +80°C (temperature range of -60°C to +80°C available as an option)

Certification:

Each unit comes fully certified with a test certificate or an EC Declaration of Conformity stating compliance with the essential health and safety requirements of the Machinery Directive 2006/42/EC.

Noiseless 1200lb model:

This model is equipped with a patented quiet brake design that is virtually silent and fully automatic. Best suited to those locations where quiet is required, such as schools, hospitals and theatres.

Corrosion Protection Option:

This model is protected using our unique formulation giving unprecedented long term reliability and superior corrosion resistance and protection in the most severe conditions. The coating provides excellent friction protection and has been proven to be effective through at least 1000 hours of the ASTM B 117 Salt Spray Test. The coating gives the properties of stainless steel without the cost implications.

Dual Handle Option:

Our BHW range can be modified with a new style pinion shaft that allows the handle to be fitted on either or both sides of the winch; this has been designed for areas with difficult access or situations when the conventional right handed winch handle isn’t suitable.

For BHW winches with a dual handled pinion shaft, the BHW-0800 (800lb) and BHW-1200 (1200lb) models are supplied with two handles, as the fittings for each side are not the same. The BHW-1800 (1800lb) and BHW-2600 (2600lb) models come with one handle that fits on either side. If a handle is required to be fitted on both sides of either the 1800lb or 2600lb models, please ask us for more details. The dual handle pinion shaft for the noiseless version (BHW-1200N) is not generally available from stock but may be available as an option – please contact us if this is your preferred design.



Due to our policy of continual product development, dimensions, weights and specifications may change without prior notice. Please check with your Tiger sales team when ordering.

Winch Table

Product Code Pulling Capacity (lbs/kg) Lifting Capacity (lbs/kg) Gear Ratio Hub Diameter (mm) Handle Length (mm) Unit Weight (kg) Cable Diameter (mm/lbs) Cable Storage Cap. (m) Strap Storage Cap. (m) Technical Drawing
1st Layer Mid Layer Last Layer
BHW-0800 800/360 800/360 560/254 400/180 4.1:1 Ø40 160 3.0 Ø4/Ø5/32 36 9.1
BHW-1200 1200/550 1200/550 864/392 600/275 4.1:1 Ø50 210 3.5 Ø5/Ø3/16 23 8.5
BHW-1200-N 1200/550 1200/550 864/392 600/275 4.1:1 Ø50 210 4.0 Ø5/Ø3/16 23 8.5
BHW-1800 1800/800 1800/800 1239/562 900/400 5:1 Ø70 320 8.0 Ø6/Ø1/4 24 14.1
BHW-2600 2600/1180 2600/1180 1861/844 1300/590 10:1 Ø82 320 10.5 Ø8/Ø5/16 18 10.6

Winch Straps (for Pulling Only)

Product Code Description Width (mm) Thickness (mm) Breaking Load (Kg) Available For
TG-48 6 meters with safety hook 48 1.2 2068.5 BHW-800 & BHW-1200
TG-54 9 meters with safety hook 54 1.4 2864 BHW-1800
TG-60 9 meters with safety hook 60 1.7 4136 BHW-2600

Winch Wire Rope

Product Code Description Diameter (mm) Breaking Load (Kg) Available For
WWR-04-30 30 meters with safety hook 4 1270 BHW-0800
WWR-05-20 20 meters with safety hook 5 2000 BHW-1200
WWR-06-22 22 meters with safety hook 6 3000 BHW-1800
WWR-08-16 16 meters with safety hook 8 4500 BHW-2600

Y2 Elephant Lever Hoist

Elephant Lever Hoist series Y2

Capacity – 250 kg / 500 kg

Grade 100 Load Chain

Made in Japan

Specifications

Y2-25 Dimensions

Figure of YII-25 dimensions
Model
A
B
C
D
E
F
G
H
Y2-25
21
70
65
235
20
32
12
155
*All specifications herein are subject to change without prior notice.

Y2-25 Specifications

Model
Y2-25
Capacity ( ton )
0.25
Standard lift ( m )
1.0
Headroom ( mm )
235
Hand effort to lift full working load ( kg )
30
Load chain
Diameter ( mm )
4.0
No. of falls
1
Grade of chain
V
Net weight ( kg )
2.0
*All specifications herein are subject to change without prior notice.
Instruction manual

Y2-50 Dimensions

Figure of YII-50 dimensions
Model
A
B
C
D
E
F
G
H
Y2-50
26.5
83
82
265
23
36
13
284
*All specifications herein are subject to change without prior notice.

Y2-50 Specifications

Model
Y2-50
Capacity ( ton )
0.5
Standard lift ( m )
1.5
Headroom ( mm )
265
Hand effort to lift full working load ( kg )
34
Load chain
Diameter ( mm )
5.0
No. of falls
1
Grade of chain
V
Net weight ( kg )
3.6

Elephant YA Series Lever Hoist

YA series Lever Hoist by Elephant Chain Block Co. Ltd – Made in Japan

Special wear resistant Grade 100 Load Chain made by Elephant in Japan.

Light and compact design for ease of use. Durable and wear resistant.

Capacity – 0.5 Ton to 9 Tons

Standard Lift – 1.5m

YA Lever Hoist Catalog

YA-50 Lever Hoist

Specifications

YA-50 Dimensions

Figure of YA-50 dimensions
*All specifications herein are subject to change without prior notice.

YA-50 Specifications

Model
YA-50
Capacity ( ton )
0.5
Standard lift ( m )
1.2
Headroom ( mm )
240
Hand effort to lift full working load ( kg )
37
Load chain
Diameter ( mm )
4.3
No. of falls
1
Grade of chain
V
Net weight ( kg )
2.8
*All specifications herein are subject to change without prior notice.
Catalog
Instruction manual

YA-80 Dimensions

Figure of YA-80 dimensions
Model
A
B
C
D
E
F
G
H
YA-80
53
91
122
290
23
36
15
268
*All specifications herein are subject to change without prior notice.

YA-80 Specifications

Model
YA-80
Capacity ( ton )
0.8
Standard lift ( m )
1.5
Headroom ( mm )
290
Hand effort to lift full working load ( kg )
30
Load chain
Diameter ( mm )
5.6
No. of falls
1
Grade of chain
V
Net weight ( kg )
6.0
*All specifications herein are subject to change without prior notice.
Catalog
Instruction manual

YA-100 Dimensions

Figure of YA-100 dimensions
Model
A
B
C
D
E
F
G
H
YA-100
53
91
122
312
28
43
16
268
*All specifications herein are subject to change without prior notice.

YA-100 Specifications

Model
YA-100
Capacity ( ton )
1
Standard lift ( m )
1.5
Headroom ( mm )
312
Hand effort to lift full working load ( kg )
37
Load chain
Diameter ( mm )
5.6
No. of falls
1
Grade of chain
V
Net weight ( kg )
6.2
*All specifications herein are subject to change without prior notice.
Catalog
Instruction manual

YA-160 Dimensions

Figure of YA-160 dimensions
Model
A
B
C
D
E
F
G
H
YA-160
63
99
136
352
29
43
21
310
*All specifications herein are subject to change without prior notice.

YA-160 Specifications

Model
YA-160
Capacity ( ton )
1.6
Standard lift ( m )
1.5
Headroom ( mm )
352
Hand effort to lift full working load ( kg )
36
Load chain
Diameter ( mm )
7.1
No. of falls
1
Grade of chain
V
Net weight ( kg )
9.2
*All specifications herein are subject to change without prior notice.
Catalog
Instruction manual

YA-320 Dimensions

Figure of YA-320 dimensions
Model
A
B
C
D
E
F
G
H
YA-320
82.5
104
180
420
36
53
28
310
*All specifications herein are subject to change without prior notice.

YA-320 Specifications

Model
YA-320
Capacity ( ton )
3.2
Standard lift ( m )
1.5
Headroom ( mm )
420
Hand effort to lift full working load ( kg )
44
Load chain
Diameter ( mm )
9.0
No. of falls
1
Grade of chain
V
Net weight ( kg )
15.5
*All specifications herein are subject to change without prior notice.
Catalog
Instruction manual

YA-630 Dimensions

Figure of YA-630 dimensions
Model
A
B
C
D
E
F
G
H
YA-630
82.5
104
235
564
47
70
34
310
*All specifications herein are subject to change without prior notice.

YA-630 Specifications

Model
YA-630
Capacity ( ton )
6.3
Standard lift ( m )
1.5
Headroom ( mm )
564
Hand effort to lift full working load ( kg )
45
Load chain
Diameter ( mm )
9.0
No. of falls
2
Grade of chain
V
Net weight ( kg )
26.5
*All specifications herein are subject to change without prior notice.
Catalog
Instruction manual

YA-900 Dimensions

Figure of YA-900 dimensions
Model
A
B
C
D
E
F
G
H
YA-900
82.5
104
300
689
73
85
47.5
310
*All specifications herein are subject to change without prior notice.

YA-900 Specifications

Model
YA-900
Capacity ( ton )
9
Standard lift ( m )
1.5
Headroom ( mm )
689
Hand effort to lift full working load ( kg )
46
Load chain
Diameter ( mm )
9.0
No. of falls
3
Grade of chain
V
Net weight ( kg )
42.0

Elephant H 100 Series Chain Block

H-100 Series Manual Hoist by Elephant Chain Block Co. Ltd – Made in Japan

World’s Most Advance Manual Hoist – CE certified

Load Chain B39 VHC Strongest ever before.

H-100 is equipped with  new developed Grade V Load Chain – 100kg/mm2

Very Light and Compact Design

This model is also available with Overload Limit Device as an option.

ec_h_3

Yoke G100 Chain Slings

G100 2020

Yoke G100 Chain Slings – Components made in Taiwan – Assembled in India

Capacity – 1.5 Ton to 84 Tons

We offer wide range of lifting combinations to meet different customer requirements.

These products meet international Standard for Manufacturing and Safety.

Fatigue Tested / Magnet Crack Tested / Proof Load tested / Breaking Load Tested

Elebia Automatic Hook

Elebia Main Presentation

Elebia Automatic Hook – Made in Spain

Capacity – 2 Ton / 5 Ton / 10 Ton / 20 Ton / 25 Ton

Wireless Remote operated Automatic Hooks help in operation during challenging lifts where human access is either difficult or prohibited.

This product can reduce unnecessary risk of people going into hazardous environment or difficult to reach places just for hook or unhooking the load.

Beta Series Electric Chain Hoist – Single Phase

Beta Hoist

Made By Elephant in Japan

Beta Hoist Ultra Small Electric Chain Hoist

This product is a testament to great engineering and offering a humane tool.

Capacity – 125 Kgs and 200 kgs

Single Phase – 220V – 50Hz

Lightest Electric Chain Hoist in the World. Helps reduce labour and fatigue.

200 kg hoist is only 7 kgs weight with 3 meter lift height. This makes it one of a kind.

This product can help with installation and maintenance even in the most compact and difficult to reach spaces.

Beta S-020 Dimensions

Figure of BS-020 dimensions
*All specifications herein are subject to change without prior notice.

Beta S-020 Specifications

Model
Beta S-020
Capacity ( kg )
200
Motor output ( W )
180
Short – time rating ( min )
25
Load time rate ( % ED )
30
Max. starting frequency ( times / h )
180
Power Source ( V )
Single phase 100
Rated current ( A )
4
Lifting speed ( m / min )
3.8
Standard lift ( m )
3
Headroom ( mm )
280
Push-button cord length ( m )
3
Load chain, diameter x pitch ( mm )
3 x 9.3
Power Cable ( m )
3  ( 1.25 m? x 3 cores )
Net weight ( kg )
7.2
Paint Color
Main body : Silver metallic
Top & Bottom Hook : Orange
( 10R 5.5 / 14.5 )
1 ) Lifting speed is average value during lifting
2 ) Lift and length of push button cord is subject to change according to your request.
3 ) Control voltage of push button is 100V.
4 ) Headroom is less than above value.
Specifications and dimensions are subject to change without notice.
Instruction manual

Beta H-012 Dimensions

Figure of BH-012 dimensions
*All specifications herein are subject to change without prior notice.

Beta H-012 Specifications

Model
Beta H-012
Capacity ( kg )
125
Motor output ( W )
180
Short – time rating ( min )
25
Load time rate ( % ED )
30
Max. starting frequency ( times / h )
180
Power Source ( V )
Single phase 200 – 220
Rated current ( A )
2
Lifting speed ( m / min )
6.5
Standard lift ( m )
3
Headroom ( mm )
280
Push-button cord length ( m )
3
Load chain, diameter x pitch ( mm )
3 x 9.3
Power Cable ( m )
3  ( 1.25 m? x 3 cores )
Net weight ( kg )
7.2
Paint Color
Main body : Silver metallic
Top & Bottom Hook : Orange
( 10R 5.5 / 14.5 )
1 ) Lifting speed is average value during lifting
2 ) Lift and length of push button cord is subject to change according to your request.
3 ) Control voltage of push button is 200 – 220V.
4 ) Headroom is less than above value.
Specifications and dimensions are subject to change without notice.
Instruction manual

Beta H-020 Dimensions

Figure of BH-012 dimensions
*All specifications herein are subject to change without prior notice.

Beta H-020 Specifications

Model
Beta H-020
Capacity ( kg )
200
Motor output ( W )
180
Short – time rating ( min )
25
Load time rate ( % ED )
30
Max. starting frequency ( times / h )
180
Power Source ( V )
Single phase 200 – 220
Rated current ( A )
2
Lifting speed ( m / min )
3.8
Standard lift ( m )
3
Headroom ( mm )
280
Push-button cord length ( m )
3
Load chain, diameter x pitch ( mm )
3 x 9.3
Power Cable ( m )
3  ( 1.25 m? x 3 cores )
Net weight ( kg )
7.2
Paint Color
Main body : Silver metallic
Top & Bottom Hook : Orange
( 10R 5.5 / 14.5 )
1 ) Lifting speed is average value during lifting
2 ) Lift and length of push button cord is subject to change according to your request.
3 ) Control voltage of push button is 200 – 220V.
4 ) Headroom is less than above value.
Specifications and dimensions are subject to change without notice.



Alpha Series Electric Chain Hoist

alpha hoist 2

Alpha Series Hoist

Capacity – 60 kg to 500 kgs

Single Phase – 200 – 220V – 50Hz

Single Speed and Variable Speed options available

Hoist can be made available in the following combinations

  1. Hook at top
  2. Plain Trolley
  3. Gear Trolley
  4. Electric Trolley

Air Winch

Tiger Air Winch for Industrial Applications

Capacity – 0.5 Ton to 3 Ton

Air Supply – 4 Bar to 6 Bar

Air Hoist

Tiger Air Hoist for Industrial Applications

Capacity – 0.25 Ton to 20 Ton

Air Supply – 4 Bar to 6 Bar

HW-2000 Hand Winch

This winch can also be ceiling mounted.

  • 2000lb/900kg capacity
  • Can be ceiling mounted with loop drive
  • Operating temperature -40°C to +80°C (temperature range of -60°C to +80°C available as an option)
  • Available in regular or split reel, which allows for operation of two line or cables for greater versatility
  • Available in handle or loop drive models

BHW Brake Hand Winch

The original brake hand winch

The Tiger Brake Winch is a high quality multi-purpose winch used for a wide variety of lifting and hoisting applications. The automatic brake ensures the load remains suspended when the crank is released and avoids unchecked descent of the load; there is no freewheeling making the hand winch extremely safe to operate. All the mechanical components are enclosed for protection against dust, dirt and rain contamination. This equipment has a lifting capacity ranging from 800lbs to 2600lbs. The BHW is compact and lightweight yet rugged and durable.

These units meet and exceed all the requirements within BS EN 13157: 2004+A1:2009.

Manual Winch GM-30

MAXPULL MACHINERY & ENGINEERING Co.,LTD.
Headquarters and Factory
1296-22, Nakaya, Nishifukai, Nagareyama-shi
Chiba 270-0107 JAPAN

Founded in 1976 as a specialist winch manufacturer in Japan.

Main Features :

  • Performance
  • Safety
  • Durability
  • Compactness
  • Ergonomic

The Maxpull winch is World Class. Gravity is our only rival

Carefully selected materials as well as advanced design and technology provide the extremely high safety. We have enhanced the strength of the portions where load is intensively applied by combining a precision press-processing rib or double plate.Select Model GM when the handle can rotate 360 degrees.

* Ease of operation
If you compare our product with others, the handle force during operation is very small and work is easy because of its high-level mechanical efficiency. This winch is light and very convenient to carry for the compact design. Users can install the winch easily using the prescribed bolts. In addition, the each part is made by press work and the whole of winch is assembled with bolts, so it is easily disassembled. Anyone can repair and assemble this winch by just purchasing necessary replacing parts and installing them according to the instructions in the manual.

* Outstanding durability
Ball bearings only from leading manufacturers are used for all bearings. The bearing allows smooth lifting and offers outstanding resistance against wear. Our unique profile shifted gear that performed special heat treatment is used for the gear reducer, and it allow you to work securely. The automatic brake has outstanding durability because it has the mechanism that can adjust the gap as desired. Baking finish performed on the surface is resistant to rust. It is strong and can be used in any location.

* Reliable safety
Carefully selected materials as well as advanced design and technology provide the extremely high safety. We have enhanced the strength of the portions where load is intensively applied by combining a precision press-processing rib or double plate. A fail-safe mechanism is employed for the mechanical brake, so it never enters the state of no brake even if the impact is applied to a stopper arm. The method of anchoring the wire rope to the drums is a fail-safe structure with a special drum that an extra maintenance winding is maintained. Users can easily and surely anchor the end of a wire rope to the drum by using the attached hex wrench. The above features are all enabled thanks to our unique reliable safety design.



Model GM-30
Max capacity  29400N (3000kgf) 12? Winding of a wire rope up to 3rd layer
Drum capacity  12X35m
Gear ratio  1/35.5
Handle force 1  1st layer : 137N (13.9kgf)
Handle force 2  2nd layer : 169N (17.2kgf)
Handle force 3  3rd layer : 201N (20.5kgf)
Handle length  370mm
Weight  37.7 kg

Manual Winch GM-20

MAXPULL MACHINERY & ENGINEERING Co.,LTD.
Headquarters and Factory
1296-22, Nakaya, Nishifukai, Nagareyama-shi
Chiba 270-0107 JAPAN

Founded in 1976 as a specialist winch manufacturer in Japan.

Main Features :

  • Performance
  • Safety
  • Durability
  • Compactness
  • Ergonomic

The Maxpull winch is World Class. Gravity is our only rival

Carefully selected materials as well as advanced design and technology provide the extremely high safety. We have enhanced the strength of the portions where load is intensively applied by combining a precision press-processing rib or double plate.Select Model GM when the handle can rotate 360 degrees.

* Ease of operation
If you compare our product with others, the handle force during operation is very small and work is easy because of its high-level mechanical efficiency. This winch is light and very convenient to carry for the compact design. Users can install the winch easily using the prescribed bolts. In addition, the each part is made by press work and the whole of winch is assembled with bolts, so it is easily disassembled. Anyone can repair and assemble this winch by just purchasing necessary replacing parts and installing them according to the instructions in the manual.

* Outstanding durability
Ball bearings only from leading manufacturers are used for all bearings. The bearing allows smooth lifting and offers outstanding resistance against wear. Our unique profile shifted gear that performed special heat treatment is used for the gear reducer, and it allow you to work securely. The automatic brake has outstanding durability because it has the mechanism that can adjust the gap as desired. Baking finish performed on the surface is resistant to rust. It is strong and can be used in any location.

* Reliable safety
Carefully selected materials as well as advanced design and technology provide the extremely high safety. We have enhanced the strength of the portions where load is intensively applied by combining a precision press-processing rib or double plate. A fail-safe mechanism is employed for the mechanical brake, so it never enters the state of no brake even if the impact is applied to a stopper arm. The method of anchoring the wire rope to the drums is a fail-safe structure with a special drum that an extra maintenance winding is maintained. Users can easily and surely anchor the end of a wire rope to the drum by using the attached hex wrench. The above features are all enabled thanks to our unique reliable safety design.



Model GM-20
Max capacity 19600N (2000kgf) 9? Winding of a wire rope up to 3rd layer
Drum capacity 9X38m / 10 x 38m
Gear ratio 1/20 quick winding 1/4
Handle force 1 1st layer : 157N (16.0kgf)
Handle force 2 2nd layer : 186N (18.9kgf)
Handle force 3 3rd layer : 214N (21.8kgf)
Handle length 370mm
Weight 28.2 kg

Manual Winch GM-10

MAXPULL MACHINERY & ENGINEERING Co.,LTD.
Headquarters and Factory
1296-22, Nakaya, Nishifukai, Nagareyama-shi
Chiba 270-0107 JAPAN

Founded in 1976 as a specialist winch manufacturer in Japan.

Main Features :

  • Performance
  • Safety
  • Durability
  • Compactness
  • Ergonomic

The Maxpull winch is World Class. Gravity is our only rival

Carefully selected materials as well as advanced design and technology provide the extremely high safety. We have enhanced the strength of the portions where load is intensively applied by combining a precision press-processing rib or double plate.

Model GM-10
Max capacity 9800N (1000kgf) 8? Winding of a wire rope up to 3rd layer
Drum capacity ?8X35m
Gear ratio 1/12.6
Handle force 1 1st layer : 133N (13.5kgf)
Handle force 2 2nd layer : 157N (16.0kgf)
Handle force 3 3rd layer : 182N (18.5kgf)
Handle length 300mm
Weight 16.4 kg

Manual Winch GM-5

MAXPULL MACHINERY & ENGINEERING Co.,LTD.
Headquarters and Factory
1296-22, Nakaya, Nishifukai, Nagareyama-shi
Chiba 270-0107 JAPAN

Founded in 1976 as a specialist winch manufacturer in Japan.

Main Features :

  • Performance
  • Safety
  • Durability
  • Compactness
  • Ergonomic

The Maxpull winch is World Class. Gravity is our only rival

Carefully selected materials as well as advanced design and technology provide the extremely high safety. We have enhanced the strength of the portions where load is intensively applied by combining a precision press-processing rib or double plate.

Model GM-5
Max capacity 4900N (500kgf) 6? Winding of a wire rope up to 5th layer
Drum capacity ?6X40m
Gear ratio 1/8.9
Handle force 1 1st layer : 109N (11.1kgf)
Handle force 2 3rd layer : 142N (14.4kgf)
Handle force 3 5th layer : 174N (17.7kgf)
Handle length 250mm
Weight 15.4 kg

Manual Winch GM-3

MAXPULL MACHINERY & ENGINEERING Co.,LTD.
Headquarters and Factory
1296-22, Nakaya, Nishifukai, Nagareyama-shi
Chiba 270-0107 JAPAN

Founded in 1976 as a specialist winch manufacturer in Japan.

Main Features :

  • Performance
  • Safety
  • Durability
  • Compactness
  • Ergonomic

The Maxpull winch is World Class. Gravity is our only rival

Carefully selected materials as well as advanced design and technology provide the extremely high safety. We have enhanced the strength of the portions where load is intensively applied by combining a precision press-processing rib or double plate.

Model GM-3
Max capacity 980N (100kgf) 5? Winding of a wire rope up to 4th layer
Drum capacity ?5X35m
Gear ratio 1/1
Handle force 1 1st layer : 143N (14.6kgf)
Handle force 2 3rd layer : 187N (19.0kgf)
Handle force 3 4th layer : 208N (21.2kgf)
Handle length 250mm
Weight 7.2 kg

Manual Winch GM-1

MAXPULL MACHINERY & ENGINEERING Co.,LTD.
Headquarters and Factory
1296-22, Nakaya, Nishifukai, Nagareyama-shi
Chiba 270-0107 JAPAN

Founded in 1976 as a specialist winch manufacturer in Japan.

Main Features :

  • Performance
  • Safety
  • Durability
  • Compactness
  • Ergonomic

The Maxpull winch is World Class. Gravity is our only rival

Carefully selected materials as well as advanced design and technology provide the extremely high safety. We have enhanced the strength of the portions where load is intensively applied by combining a precision press-processing rib or double plate.

Model GM-1
Max capacity 980N (100kgf) 5? Winding of a wire rope up to 4th layer
Drum capacity 5X35m
Gear ratio 1/1
Handle force 1 1st layer : 143N (14.6kgf)
Handle force 2 3rd layer : 187N (19.0kgf)
Handle force 3 4th layer : 208N (21.2kgf)
Handle length 250mm
Weight 7.2 kg

HydraPlus

The Bridon Endurance brand – High quality performance wire ropes for the lifting industry.
Our world leading manufacturing capabilities are accompanied by a high level of quality assurance and in-house expertise in research and development and design engineering.

The Hydra is a range of high performance multi strand low rotational ropes for offshore oil and gas applications including offshore cranes, winches and A&R lines.

Benefits

  • Engineered low rotational characteristics
  • Dyform construction for crush & wear resistance
  • Enhanced radial stiffness
  • Recommended for multilayer spooling
  • Low elongation

Dyform Bristar 8

The Bridon Endurance brand – High quality performance wire ropes for the lifting industry.
Our world leading manufacturing capabilities are accompanied by a high level of quality assurance and in-house expertise in research and development and design engineering.

Benefits:

• Engineered flutes define exact location of outer strands extending bend fatigue life

• High breaking force • Flexible eight strand construction

• High temperature lubricant available

• Consistent performance

• Enhanced bending fatigue

• Superior crush resistance

• Accurate diameter tolerance

• Long life, reduced lifetime costs

• Reduced stretch

• Corrosion protected core

• Recommended for multi-layer spooling

Dyform Bristar 6

The Bridon Endurance brand – High quality performance wire ropes for the lifting industry.
Our world leading manufacturing capabilities are accompanied by a high level of quality assurance and in-house expertise in research and development and design engineering.

Benefits:

• Engineered flutes define exact location of outer strands extending bend fatigue life

• High breaking force

• Plastic Bristar profile encapsulated core

• Consistent performance

• Robust, crush resistant

• Dyform construction

• Reduced stretch

• Exceptional service life

• Corrosion protected core

• Recommended for multi-layer spooling The

Dyform 34LR PI

The Bridon Endurance brand – High quality performance wire ropes for the lifting industry.
Our world leading manufacturing capabilities are accompanied by a high level of quality assurance and in-house expertise in research and development and design engineering.

Benefits:

• Plastic impregnated – Extends fatigue life – Improves structural stability – Resists corrosion

• Low rotation

• Recommended for high lifting operations

• High strength

• Reduced rope sheave wear

• Accurate diameter, recommended for multi-layer spooling

• Suitable for single part and multi-part reeving

• Long service life

• Resistance to bending fatigue

• Reduced elongation

Dyform 8 Max

The Bridon Endurance brand – High quality performance wire ropes for the lifting industry.
Our world leading manufacturing capabilities are accompanied by a high level of quality assurance and in-house expertise in research and development and design engineering.

Benefits:

• Higher MBF than CTX

• Superior crush resistance

• Better fatigue life

• Excellent service life

• Lower downtime

• Recommended multi-layer spooling

Dyform 8

The Bridon Endurance brand – High quality performance wire ropes for the lifting industry.
Our world leading manufacturing capabilities are accompanied by a high level of quality assurance and in-house expertise in research and development and design engineering.

Benefits:

• Excellent service life

• Lower downtime

• Flexible eight strand construction

• High temperature lubricant available

• Robust crush resistant Dyform construction

• Recommended for multi-layer spooling

• Reduced lifetime costs

Dyform 6

The Bridon Endurance brand – High quality performance wire ropes for the lifting industry.
Our world leading manufacturing capabilities are accompanied by a high level of quality assurance and in-house expertise in research and development and design engineering.

Benefits:

• Exceptional service life

• Robust crush resistant Dyform construction

• Accurate diameter recommended for multi-layer spooling

• Long life, reduced lifetime costs



Diamond Blue

The diamond blue is a 6 strand galvanised conventional rope produced with a steel core fully lubricated during production process.

Benefits

  • Good strength to weight ratio
  • Corrosion resistance
  • Good fatigue performance

Blue strand 6×19 class 6×36 class

The 6 Series is a range of general purpose 6 stranded galvanised ropes produced with a steel core, fully lubricated during manufacture producing in accordance with EN 12385.

Benefits

  • Fit-for-purpose, robust rope construction
  • Fully lubricated during manufacture
  • For use on single layer drums only

Mooring Ropes

8 Strand X2-Aqua mooring ropes provides easy solutions like fast installations, better steadiness and reduction of drag on the system and because of lower diameter, there is a possibility of having downsized hardware like thimbles, which results in delivering tremendous weight and cost advantage

Features :
Higher strength to weight ratio.
Torque free and balanced construction.
Better abrasion resistance.
Chemically inert.
Excellent shape and original weight retention.
Excellent shock absorption capacity, Low snap-back.
Higher strength compared to Nylon.

3 Strand Polypropylene Ropes

3 Strand Polypropylene Ropes or PP Ropes by Garware supplied by M.A.Zavery & Co. are widely used in Fisheries. Full Specifications for Garware PP Ropes could be found in the PDF File available for download.

Features :
High strength at lower weights.
Highly resistant to acids and alkalies.
Floats in water, does not absorb water.
Low elongation.
High abrasion resistance due to special construction.
Better knot ability.

Safety Nets

Safety Nets by Garware supplied by M.A.Zavery & Co. are widely used by people as it is one of a kind Solution for Fall Protection. Garware Safety Nets has application in Construction Industry. Full Specifications for Garware Safety Nets could be found in the PDF File available for download.

Features :
Available in Braided Twine Nets, Twisted Twine Nets, Knotless Nets, Knotted Nets.
Available in standard as well as customised sizes.
Can be supplied along with containment net for arresting smaller debris.
Equipped with high strength border ropes and tie cords for easy & reliable installation.
High strength & durability for excellent shock absorption.
Heat treated for better knot stability & preventing skewing.
Machine made nets for uniform mesh size.
Resistant to degradation due to UV rays.
PPMF K’less safety nets tested and certified as per EN 1263-1:2002 available.
Triple layered safety nets for better safety at high rise buildings installed at some premium projects in India.

G-100 Clevis Grab Hook.

Not for use with Omega Link. No reduction of working load limit, thanks to supporting wings which prevent chain link deformation. ? Design factor 4:1 proof tested and certified.

G-100 Eye Grab Hook.

Not for use with Omega Link. No reduction of working load limit, thanks to supporting wings which prevent chain link deformation. ? Design factor 4:1 proof tested and certified.

G-100 Swivel Self Locking Hook

Design factor 4:1 proof tested and certified. WARNING INFORMATION: This hook is a positioning device and is not intended to rotate under load. For swivel hooks designed to rotate under load, please refer to X-027N.

X-001 Welded Master Link

Welding Oblong Master Links.

Design factor 5:1 proof tested and certified.

?Available from Q1, 2019

Freedom Series Self Lubricating Chain

Freedom Series Self-Lubricating Chains performs well in the application without additional lubrication.
Oil impregnated sintered steel bushing provides self-lubricating and it is ideal for the industries that cleanliness is critical such as packaging, printing, food processing, textile and so on.
Moreover it is designed for applications where regular maintenance is not easily accessible.

Wear Resistance:

  • In dusty environments, dusts absorb the lubrication of sintered steel bushings and it causes premature wear.
  • Used in water, the chain wears quickly.
  • Range of speed is from slow speed 25m/min to high speed 75m/min.
  • When lubrication depletes in the sintered steel bushings, the chain wears abruptly.
  • Operating temperature is from -10? to 150?.
    When ambient temperature is over 80?, lubrication seeps out quickly.
  • The sintered bushings are heat treated, and allow standard chain selection.
  • An application of sintered steel bushing associated with shock load is not appropriate.

O Ring Chain

O Ring Chain is with O Ring to maintain lubricant oil. It is recommended for the condition oiling is difficult or impossible, oil may cause some residual problem, or having dust.

Heavy Duty Roller Chain

Heavy Duty Roller Chain is recommended for machine and equipment working under extremely tough load and impact condition such as steel mill (Furnace Door, Draw Bench), earth moving & construction equipment, amusement park facilities, and others. Main parts are hardened specialty steel with precious machining.

HE Roller Chain

HE Roller Chain consist of thicker link plate than ANSI Roller Chain and stronger pin with hi strength steel, which creates higher tensile strength and higher fatigue strength.
Standard Sprocket can be used for single strand, but need special sprocket for double or triple strand chain.

Plated Roller Chain

SENQCIA provides Nickel plated and LL (special surface treatment) plated Roller Chain for higher corrosion resistance than regular ANSI Roller Chain.

Stainless Roller Chain

Stainless Roller Chain are made of SUS300, and recommended for application under severe environment such as acid or alkaline environment, with water, and low or high temperature.

Super Roller Chain

Super Roller Chain is designed to make outstanding resistance against fatigue and impact.

Link Plate
  • Oval Shaped Link Plate
  • High Accuracy Hole by Ball Drift
Pin
  • High strength steel
  • All surface coined
Bushing & Roller
  • Seamless

ANSI Roller Chain

ANSI Roller Chain is standing on JIS B 1801. The uniqueness includes SBR (Solid Bushing & Roller) having no seam on bushing and roller which creates outstanding character against initial elongation and wear.

Features:

  • Outstanding longer wear life

  • Up to 2-3 times longer wear life over curled bushings

  • Relaiable performance

8-097 / Clevis C Hook

? Design factor 4:1 proof tested and certified Tested ace. to DIN EN 1677
Code”FE”

8-091 / Clevis Choker

? Design factor 4:1 proof tested and certified Tested ace. to DIN EN 1677
Code”YF”

8-088 / Insulated Blank Swivels

? Design factor 4:1 proof tested and certified. Tested ace. to DIN EN 1677 Individually tested to resist 1500 Volts insulated with Test Certificate. Design for protection of overhead crane during welding operatio ns on suspended loads.
Code ” BSI “

8-080 / Eye Swivels

? Design factor 4:1 proof tested and certified. Tested ace. to DIN EN 1677 WARNING INFORMATION:This hook is a positioning device and is not intended to rotate under load.

8-060 / Clevis Clutch

? Design factor 4:1 proof tested and certified. Tested ace. to DIN EN 1677
Code “KC”

8-050 / Shank Coupling

** d min.: the smallest shank dimension after machining. Note: After machining the shank, proof loading must be carried out.
Code “EA”

8-049N / Eye Swivel Hook

Ball bearing performs to fully swivel under load. ? Design factor 4:1 proof tested and certified Tested ace. to DIN EN 1677
Code “YSWN “

8-049 / Eye Swivel Hook

? Design factor 4:1 proof tested and certified Tested ace. to DIN EN 1677 WARNING INFORMATION:This hook is a positioning device and is not intended to rotate under load. For swivel hooks designed to rotate under load, see pages 93 8-049N.
Code ” YSW “

8-048 / Shackle Eye Swivel Hook

? Design factor 4:1 proof tested and certified. Tested ace. to DIN EN 1677 WARNING INFORMATION:This hook is a positioning device and is not intended to rotate under load.
Code “YSWX”

8-045 / Shank Sling Hook

**d min.: the smallest shank dimension after machining. Note: After machining the shank proof loading must be carried out. ? Design factor 4:1
Code “FH”

8-042 / Clevis Grab Hook.

Not for use with Omega Link Item. 8-018 No reduction of working load limit, thanks to supporting wings which prevent chain link deformation. ? Design factor 4:1 proof tested and certified. Tested ace. to DIN EN 1677
Code “YK”

8-041 / Eye Grab Hook

Not for use with Omega Link Item. 8-018 No reduction of working load limit, thanks to supporting wings which prevent chain link deformation. ? Design factor 4:1 proof tested and certified. Tested ace. to DIN EN 1677
Code”YH”

8-039 / Eye Sling Hook

with latch ? Design factor 4:1 proof tested and certified Tested ace. to DIN EN 1677
Code “EL”

8-028 / Round Sling Self Locking Hook

YOKE Roundsling Self Locking Hook is designed in a way to solve your synthetic end-fitting problems. The Roundsling Self Locking Hook presents following utmost benefits : 1. The Round Shape is designed to provide great protection to your synthetic roundsling on everyloading. 2. Offer complete range of hooks from 1 tonnes up to 21.2 tonnes. 3. Assembly is fast and easy with only a hammer required. 4. The hook with Self Locking function meets real safe and safer required. 5. Acquired H91 certificate approved by BG German company. ? Design factor 4:1 proof tested and certified.

8-027N / Swivel Self Locking Hook

Ball bearing performs to fully swivel under load. ? Design factor 4:1 proof tested and certified Tested ace. to DIN EN 1677
Code “YEN”

8-024 / Shank Self Locking Hook

** d min. = the smallest shank dimension after machining. Note: After machining the shank, proof loading must be carried out. ? Design factor 4:1
Code “YEA”

8-023 / Coupling Self Locking Hook

YOKE’s innovative, fine design with ” Coupling Pin ” system hook is able to solve any of your problems in Chain, Wire Rope and Synthetic Slings. The hook : 1. Create safer lifting with the use of ” Self Locking ” system. 2. Assembly is fast and easy with only a hammer required. 3. Acquired H91 certificate approved by BG German company. 4. Patent :Taiwan, China, France, Germany, Italy, Japan,USA,Switzerland.
Code “YL”

8-021N / Shackle Swivel Hook

Ball bearing performs to fully swivel under load. ? Design factor 4:1 proof tested and certified. Tested ace. to DIN EN 1677
Code ” EHYN “

8-018 / Omega Link

? Design factor 4:1 proof tested and certified. Tested ace. to DIN EN 1677
Code”YO”

8-003F / Oblong Master Link with Flat

Connected to Chain with “YO” Omega Link. * Forged Oblong Master Links. ? Design factor 5:1 Proof tested and certified WLL=Working Load Limit Tested ace. to EN 1677
Code”MFF”

8-003 / Oblong Master Link

Connected to Chain with “YA” connecting link. ? Forged Oblong Master Links. Design factor 4:1 proof tested and certified. Tested acc. to EN 1677
Code “MF”.

8-522 / Trawl Block with Swivel Eye

?Forged swivel eye and sheave, pressed side plates with extra throat opening allowing nets and fittings to pass through. ?Hot dipped galvanized finish provides corrosive resistance in salt water environment. ?Supplied with bronze bushing and pressure lube fittings. ?Individually tested for maximum safety

8-523 / Trawl Block with Swivel Eye

?All parts are forged: swivel eye, side plates and sheave. ?Hot dipped galvanized finish provides corrosive resistance in salt water environment. ?Supplied with tapered bearings and pressure lube fittings. ?Individually tested for maximum safety.

8-521 / Trawl Block with Swivel Eye

?All parts are forged: swivel eye, side plates and sheave. ?Hot dipped galvanized finish provides corrosive resistance in salt water environment. ?Supplied with needle bearings and pressure lube fittings. ?Individually tested for maximum safety.

8-515 / Hay Fork Pulley with Swivel Eye

?YOKE Hay Fork Pulley features one piece pressed steel shell and forged hook. ?Rounded edges to prevent rope damages. ?Supplied with bronze bushings and pressure lube fittings. ?Manila rope and wire line applications

8-514 / Hay Fork Pulley with Swivel Eye

?YOKE Hay Fork Pulley features one piece pressed steel shell and forged hook. ?Rounded edges to prevent rope damages. ?Supplied with bronze bushings and pressure lube fittings. ?Manila rope and wire line applications

8-512 / Hay Fork Pulley with Swivel Hook

?YOKE Hay Fork Pulley features one piece pressed steel shell and forged hook. ?Rounded edges to prevent rope damages. ?Supplied with bronze bushings and pressure lube fittings. ?Manila rope and wire line applications

8-504 / Snatch Block with Swivel Eye

?YOKE Snatch Blocks are manufactured of the highest quality tensile steel. ?Part number, wire rope size and working load limit are marked on each block. ?Permanent batch codes link to test certificates for easy traceability. ?Supplied with bronze bushings and pressure lube fittings. ?Meets or exceeds all requirements of ASME B30.26. ?Safety factor 4:1 ?Fatigue rated

8-500 / Sheaves for Snatch Block

?YOKE Sheaves are manufactured of the highest quality tensile steel. ?Available for wire rope sizes 8mm to 32mm. ?Permanent batch codes link to test certificates for easy traceability.

8-573 / Alloy HC Tail Board

?YOKE Alloy HC Snatch Blocks are manufactured of the highest quality alloy steel. ?Available from 25 tonnes to 30 tonnes, for wire rope sizes 25mm to 32mm. ?Part number, wire rope size and working load limit are marked on each block. ?Permanent batch codes link to test certificates for easy traceability. ?Supplied with bronze bushings and pressure lube fittings. ?Meets or exceeds all requirements of ASME B30.26. ?Safety factor 4:1 ?Fatigue rated

8-572 / Alloy HC Snatch Block With Hook

?YOKE alloy snatch blocks are manufactured from the highest quality alloy steel. ?YOKE alloy snatch blocks are available in sizes of 25 tonnes to 30 tonnes. ?YOKE alloy snatch blocks are designed with a safety factor of 4 : 1. ?YOKE alloy snatch blocks are available for wire rope sizes 1″ to 1 1/8″. ?YOKE alloy snatch blocks are supplied with model number, wire diameter and working load limit. ?YOKE alloy snatch blocks are supplied with test cer ts and batch numbers for ease of traceability. ?YOKE alloy snatch blocks are manufactured with bronze bushings and grease fitting for ease of use and extended sheave life. ?Fatigue rated.

8-571 / Alloy HC Snatch Block With Shackle

?YOKE Alloy HC Snatch Blocks are manufactured of the highest quality alloy steel. ?Available from 25 tonnes to 30 tonnes, for wire rope sizes 25mm to 32mm. ?Part number, wire rope size and working load limit are marked on each block. ?Permanent batch codes link to test certificates for easy traceability. ?Supplied with bronze bushings and pressure lube fittings. ?Meets or exceeds all requirements of ASME B30.26. ?Safety factor 4:1 ?Fatigue rated

8-563 / Alloy Tail Board

?YOKE Alloy Snatch Blocks are manufactured of the highest quality alloy steel. ?Available in 12 tonnes, for wire rope sizes 19mm to 22mm. ?Part number, wire rope size and working load limit are marked on each block. ?Permanent batch codes link to test certificates for easy traceability. ?Supplied with bronze bushings and pressure lube fittings. ?Meets or exceeds all requirements of ASME B30.26. ?Safety factor 4:1 ?Fatigue rated

8-562 / Alloy Snatch Block with Hook

?YOKE Alloy Snatch Blocks are manufactured of the highest quality alloy steel. ?Available in 12 tonnes, for wire rope sizes 19mm to 22mm. ?Part number, wire rope size and working load limit are marked on each block. ?Permanent batch codes link to test certificates for easy traceability. ?Supplied with bronze bushings and pressure lube fittings. ?Meets or exceeds all requirements of ASME B30.26. ?Safety factor 4:1 ?Fatigue rated

8-561 / Alloy Snatch Block with Shackle

?YOKE Alloy Snatch Blocks are manufactured of the highest quality alloy steel. ?Available in 12 tonnes, for wire rope sizes 19mm to 22mm. ?Part number, wire rope size and working load limit are marked on each block. ?Permanent batch codes link to test certificates for easy traceability. ?Supplied with bronze bushings and pressure lube fittings. ?Meets or exceeds all requirements of ASME B30.26. ?Safety factor 4:1 ?Fatigue rated

8-553 / Super Tail Board

?YOKE Super Snatch Blocks are manufactured of the highest quality tensile steel. ?Available from 20 tonnes to 30 tonnes, for wire rope sizes 25mm to 32mm. ?Part number, wire rope size and working load limit are marked on each block. ?Permanent batch codes link to test certificates for easy traceability. ?Supplied with bronze bushings and pressure lube fittings. ?Meets or exceeds all requirements of ASME B30.26. ?Safety factor 4:1 ?Fatigue rated

8-552 / Super Snatch Block With Hook

?YOKE Super Snatch Blocks are manufactured of the highest quality tensile steel. ?Available from 20 tonnes to 30 tonnes, for wire rope sizes 25mm to 32mm. ?Part number, wire rope size and working load limit are marked on each block. ?Permanent batch codes link to test certificates for easy traceability. ?Supplied with bronze bushings and pressure lube fittings. ?Meets or exceeds all requirements of ASME B30.26. ?Safety factor 4:1 ?Fatigue rated

8-551 / Super Snatch Block With Shackle

?YOKE super snatch blocks are manufactured from the highest quality tensile steel. ?YOKE super snatch blocks are available in sizes of 20 tonnes to 30 tonnes. ?YOKE super snatch blocks are designed with a safety factor of 4 : 1. ?YOKE super snatch blocks are available for wire rope sizes 1″ to 1 1/4″. ?YOKE super snatch blocks are supplied with model number, wire diameter and working load limit. ?YOKE super snatch blocks are supplied with test cer ts and batch numbers for ease of traceability. ?YOKE super snatch blocks are manufactured with bronze bushings and grease fitting for ease of use and extended sheave life. ?Fatigue rated.

8-543 / Forged Tail Board

?YOKE Forged Snatch Blocks are manufactured of the highest quality forged alloy steel. ?Available from 12 tonnes to 15 tonnes, for wire rope sizes 19mm to 22mm. ?Part number, wire rope size and working load limit are marked on each block. ?Permanent batch codes link to test certificates for easy traceability. ?Supplied with bronze bushings and pressure lube fittings. ?Meets or exceeds all requirements of ASME B30.26. ?Safety factor 4:1 ?Fatigue rated

8-542 / Forged Snatch Block with Hook

?YOKE Forged Snatch Blocks are manufactured of the highest quality forged alloy steel. ?Available from 12 tonnes to 15 tonnes, for wire rope sizes 19mm to 22mm. ?Part number, wire rope size and working load limit are marked on each block. ?Permanent batch codes link to test certificates for easy traceability. ?Supplied with bronze bushings and pressure lube fittings. ?Meets or exceeds all requirements of ASME B30.26. ?Safety factor 4:1 ?Fatigue rated

8-541 / Forged Snatch Block with Shackle

?YOKE Forged Snatch Blocks are manufactured of the highest quality forged alloy steel. ?Available from 12 tonnes to 15 tonnes, for wire rope sizes 19mm to 22mm. ?Part number, wire rope size and working load limit are marked on each block. ?Permanent batch codes link to test certificates for easy traceability. ?Supplied with bronze bushings and pressure lube fittings. ?Meets or exceeds all requirements of ASME B30.26. ?Safety factor 4:1 ?Fatigue rated

8-503 / Light Tail Board

?YOKE Light Snatch Blocks are manufactured of the highest quality tensile steel. ?Available from 2 tonnes to 8 tonnes, for wire rope sizes 8mm to 19mm. ?Part number, wire rope size and working load limit are marked on each block. ?Permanent batch codes link to test certificates for easy traceability. ?Supplied with bronze bushings and 4.5”-14” with pressure lube fittings. ?Meets or exceeds all requirements of ASME B30.26. ?Safety factor 4:1 ?Fatigue rated

8-502 / Light Snatch Block With Hook

?YOKE Light Snatch Blocks are manufactured of the highest quality tensile steel. ?Available from 2 tonnes to 8 tonnes, for wire rope sizes 8mm to 19mm. ?Part number, wire rope size and working load limit are marked on each block. ?Permanent batch codes link to test certificates for easy traceability. ?Supplied with bronze bushings and 4.5”-14” with pressure lube fittings. ?Meets or exceeds all requirements of ASME B30.26. ?Safety factor 4:1 ?Fatigue rated

8-501 / Light Snatch Block With Shackle

?YOKE Light Snatch Blocks are manufactured of the highest quality tensile steel. ?Available from 2 tonnes to 8 tonnes, for wire rope sizes 8mm to 19mm. ?Part number, wire rope size and working load limit are marked on each block. ?Permanent batch codes link to test certificates for easy traceability. ?Supplied with bronze bushings and 4.5”-14” with pressure lube fittings. ?Meets or exceeds all requirements of ASME B30.26. ?Safety factor 4:1 ?Fatigue rated

Swaging Hoist Hook

?YOKE Swaging Hoist Hooks are forged from special bar quality carbon steel with very special Quenched and Tempered. ?YOKE Swaging Hoist Hooks properly applied have an efficiency rating of 95% based on the catalog strength of wire rope. ?YOKE Swaging Hoist Hooks are recommended for use with 6 x 19 or 6 x 37,IPS or XIP, FC or IWRC wire rope. ?YOKE Swaging Hoi st Hooks are not recommended for use on fiber core or lang lay rope.
All slings swaged with Sockets shall be proof loaded in accordance with ANSI B30.9

Forged Closed Spelter Wire Rope Socket.

?YOKE Spelter Sockets are forged from special bar quality carbon steel with very finest hardness controlled. ?YOKE Spelter Sockets properly applied have an efficiency rating of 100% based on the catalog strength of wire rope. ?Socket size 1/4″ thru 3/4″ use one groove,7/8″ thru 1-1/2″ use 2 grooves. ?Closed Spelter Sockets meet the performance requirements of Federal Specification RR-S-550E,Type B.
In accordance with ASME B30.9 all assembly slings with poured Spelter Sockets, shall be proof loaded.

Forged Open Spelter Wire Rope Socket

?YOKE Spelter Sockets are forged from special bar quality carbon steel with very finest hardness controlled. ?YOKE Spelter Sockets properly applied have an efficiency rating of 100% based on the catalog strength of wire rope. ?Socket size 1/4″ thru 3/4″ use one groove, 7/8″ thru 1-1/2″ use 2 grooves. ?Open Spelter Sockets meet the performance requirements of Federal Specification RR-S-550E,Type A. ? S.C. = Self Colored.
In accordance with ASME B30.9 all assembly slings with poured Spelter Sockets, shall be proof loaded.

Forged Open Spelter Wire Rope Socket

?YOKE Spelter Sockets are forged from special bar quality carbon steel with very finest hardness controlled. ?YOKE Spelter Sockets properly applied have an efficiency rating of 100% based on the catalog strength of wire rope. ?Socket size 1/4″ thru 3/4″ use one groove,7/8″ thru 1-1/2″ use 2 grooves. ?Open Spelter Sockets meet the performance requirements of Federal Specification RR-S-550E,Type A. ? S.C. = Self Colored.
In accordance with ASME B30.9 all assembly slings with poured Spelter Sockets, shall be proof loaded.

Forged Closed Swage Wire Rope Socket.

?YOKE 8-732 Closed Swage Sockets are forged from special bar quality carbon steel with very finest hardness controlled by spheroidize annealing. ?YOKE Swage Sockets properly applied have an efficiency rating of 100% based on the catalog strength of wire rope. ?YOKE Swage Sockets are recommended for use with 6×19, 6×37, and IWRC wire rope. They are approved for use with galvanized bridge rope. ?YOKE Swage Sockets are not recommended for use on fiber core or lang lay rope. ? S.C. = Self Colored.
All slings swaged with Sockets shall be proof loaded in accordance with ANSI B30.9

Forged Open Swage Socket(with Round Pin)

?YOKE 8-731 Opened Swage Sockets are forged from special bar quality carbon steel with very finest hardness controlled by spheroidize annealing. ?YOKE Swage Sockets properly applied have an efficiency rating of 100% based on the catalog strength of wire rope. ?YOKE Swage Sockets are recommended for use with 6×19, 6×37, and IWRC wire rope. They are approved for use with galvanized bridge rope. ?YOKE Swage Sockets are not recommended for use on fiber core or lang lay rope.
All slings swaged with Sockets shall be proof loaded in accordance with ANSI B30.9

Forged Open Swage Wire Rope Socket(with Safety Bolt Pin)

?YOKE 8-730 Opened Swage Sockets are forged from special bar quality carbon steel with very finest hardness controlled by spheroidize annealing. ?YOKE Swage Sockets properly applied have an efficiency rating of 100% based on the catalog strength of wire rope. ?YOKE Swage Sockets are recommended for use with 6×19, 6×37, and IWRC wire rope. They are approved for use with galvanized bridge rope. ?YOKE Swage Sockets are not recommended for use on fiber core or lang lay rope.
All slings swaged with Sockets shall be proof loaded in accordance with ANSI B30.9

8-838 Forged Anchor Shackle

?Shackles are Type Approved by DNV & ABS. ?Shackles are forged carbon steel with alloy pin. ?Size and Working Load Limit permanently shown on each shackle. ?All shackles with Batch Code which links to Test Certificate and quality traceability. ?100% magnaflux crack detection during manufacturing. ?20,000 cycle fatigue rated to 1.5 times Working Load Limit. ? Minimum Ultimate Load is 6 times the Working Load Limit. Maximun Proof Load is 2 times the W orking Load Limit.
YOKE 8-838 Carbon Bolt Type Anchor Shackles meet the performance requirements of Federal Specification RR-C-271D, Type 4A, Grade A, Class 3.

8-837 Forged Anchor Shackle

?Shackles are Type Approved by DNV & ABS. ?Shackles are forged carbon steel with alloy pin. ?Size and Working Load Limit permanently shown on each shackle. ?All shackles with Batch Code which links to Test Certificate and quality traceability. ?100% magnaflux crack detection during manufacturing. ?20,000 cycle fatigue rated to 1.5 times Working Load Limit. ? Minimum Ultimate Load is 6 times the W orking Load Limit. Maximun Proof Load is 2 times the W orking Load Limit.
YOKE 8-837 Carbon Bolt Type Anchor Shackles meet the performance requirements of Federal Specification RR-C-271D, Type 4A, Grade A, Class 2.

8-835 Forged Chain Shackle

?Shackles are Type Approved by ABS. ?Shackles are forged carbon steel with alloy pin. ?Size and Working Load Limi t permanently shown on each shackle. ?All shackles with Batch Code which links to Test Certificate and quality traceability. ?100% magnaflux crack detection during manufacturing. ?20,000 cycle fatigue rated to 1.5 times Working Load Limit. ? Minimum Ultimate Load is 6 times the W orking Load Limit. Maximun Proof Load is 2 times the W orking Load Limit.
YOKE 8-835 Bolt Type Anchor Shackles meet the performance requirements of Federal Specification RR-C-271D, Type 4B , Grade A, Class 3.

8-834 Forged Chain Shackle

?Shackles are Type Approved by ABS. ?Shackles are forged carbon steel with alloy pin. ?Size and Working Load Limit permanently shown on each shackle. ?All shackles with Batch Code which links to Test Certificate and quality traceability. ?100% magnaflux crack detection during manufacturing. ?20,000 cycle fatigue rated to 1.5 times Working Load Limit. ? Minimum Ultimate Load is 6 times the W orking Load Limit. Maximun Proof Load is 2 times the W orking Load Limit.
YOKE 8-834 Screw Pin Chain Shackles meet the performance requirements of Federal Specification RR-C-271D, Type 4B , Grade A, Class 2.

8-808 Forged Alloy Anchor Shackle

?Shackles are Type Approved by DNV & ABS. ?Shackles are forged alloy steel with alloy pin. ?Size and Working Load Limit permanently shown on each shackle. ?All shackles with Batch Code which links to Test Certificate and quality traceability. ?100% magnaflux crack detection during manufacturing. ?20,000 cycle fatigue rated to 1.5 times Working Load Limit. ? Minimum Ultimate Load is 5 times the Working Load Limit. Maximun Proof Load is 2 times the W orking Load Limit.
YOKE 8-808 Bolt Type Anchor Shackles meet the performance requirements of Federal Specification RR-C-271D, Type 4A , Grade B, Class 3.

8-807 Forged Alloy Anchor shackle

?Shackles are Type Approved by DNV & ABS. ?Shackles are forged alloy steel with alloy pin. ?Size and Working Load Limit permanently shown on each shackle. ?All shackles with Batch Code which links to Test Certificate and quality traceability. ?100% magnaflux crack detection during manufacturing. ?20,000 cycle fatigue rated to 1.5 times Working Load Limit. ? Minimum Ultimate Load is 5 times the Working Load Limit. Maximun Proof Load is 2 times the W orking Load Limit.
YOKE 8-807 Screw Pin Anchor Shackles meet the performance requirements of Federal Specification RR-C-271D, Type 4A , Grade B, Class 2.

Forged Alloy Chain Shackle

?Shackles are Type Approved by DNV & ABS. ?Shackles are forged alloy steel with alloy pin. ?Size and Working Load Limit permanently shown on each shackle. ?All shackles with Batch Code which links to Test Certificate and quality traceability. ?100% magnaflux crack detection during manufacturing. ?20,000 cycle fatigue rated to 1.5 times Working Load Limit. ? Minimum Ultimate Load is 5 times the W orking Load Limit. Maximun Proof Load is 2 times the W orking Load Limit.
YOKE 8-805 Bolt Type Anchor Shackles meet the performance requirements of Federal Specification RR-C-271D, Type 4B , Grade B, Class 3.

Forged Alloy Chain Shackle (with Screw Pin)

?Shackles are Type Approved by DNV & ABS. ?Shackles are forged alloy steel with alloy pin. ?Size and Working Load Limit permanently shown on each shackle. ?All shackles with Batch Code which links to Test Certificate and quality traceability. ?100% magnaflux crack detection during manufacturing. ?20,000 cycle fatigue rated to 1.5 times Working Load Limit. ? Minimum Ultimate Load is 5 times the Working Load Limit. Maximun Proof Load is 2 times the W orking Load Limit.
YOKE 8-804 Bolt Type Anchor Shackles meet the performance requirements of Federal Specification RR-C-271D, Type 4B , Grade B, Class 2.

Forged Alloy Wide Body Shackle (with Bolt Pin)

?Shackles are forged alloy steel with alloy pin. ?Size and the Working Load Limit permanently shown on each shackle. ?All shackles with Batch Code which links to Test Certificate and quality traceability. ?100% magnaflux crack detection during manufacturing. ?20,000 cycle fatigue rated to 1.5 times Working Load Limit. ? Minimum Ultimate Load is 5 times the W orking Load Limit. Maximun Proof Load is 2 times the W orking Load Limit. ? 8-809-19/-26 See Figure 1 ? 8-809-32/-38

ROV Anchor Shackle

Minimum Utimate Load is 5 times the Working Load Limit

Maximun Proof Load is 2 times the Working Load Limit

ROV Anchor Shackle

Minimum Utimate Load is 5 times the Working Load Limit

Maximun Proof Load is 2 times the Working Load Limit

DA 808 Shackle

2t to 35t are type approved of DNV2.7-1. Minimum Ultimate Load is 8 times the Working Load Limit.

85t to 175t meet all requirements of DNV 2.7-1.Minimum Utimate Load is 5.4 times the Working Load Limit.

DA 838 Shackle

2t to 35t are type approved of DNV2.7-1. Minimum Ultimate Load is 6 times the Working Load Limit. 55t to 150t meet all requirements of DNV 2.7-1.Minimum Utimate Load is 6 times the Working Load Limit.

8-082

  • Pivots 180°, designed minimizes head room
  • Manufactured from forged alloy steel, quenched and tempered.
  • Manufactured and tested in accordance with EN1677-1.
  • Certified by DGUV GS-OA-15-04.
  • Load rated parts are 100% magnaflux crack detected.
  • Individual forged parts are traceable to Test Certification.
  • Proof tested to 2.5 times the WLL.
  • Fatigue rated to 1.5 times the WLL.
  • The two points of attachment facilitate an even and optimal force distribution into the work piece and thus, usage of thinner base plates is possible.
  • The welding block is forged out of material with excellent welding properties.
  • Low profile design with high strength.
  • The ring is stowable thus avoiding the hazards of tripping and snagging.

8-081

  • Manufactured from forged alloy steel, quenched and tempered.
  • Manufactured and tested in accordance with EN1677-1.
  • Certified by DGUV GS-OA-15-03.
  • Load rated parts are 100% magnaflux crack detected.
  • Individual forged parts are traceable to Test Certification.
  • Proof tested to 2.5 times the WLL.
  • Fatigue rated to 1.5 times the WLL.
  • All YOKE Lifting points meet or exceed all the requirements of ASME B30.26.
  • WLL forged onto each product for quick and easy identification.
  • Lugs designed to assist the welding process.
  • A protected spring keeps the load ring in a required position. The parts are connected in such a way that they remain captive. The spring also reduces noise caused by vibrations.

Code“YX”

8-058

  • Pivots 180° and allows side load lifting.
  • Manufactured from forged alloy steel, quenched and tempered.
  • Manufactured and tested in accordance with EN1677-1.
  • Load rated parts are 100% magnaflux crack detected.
  • Individual forged parts are traceable to Test Certification.
  • Supplied without bolts; usage of Grade 10.9 or Grade 12.9 bolts is recommended.
  • Proof tested to 2.5 times the WLL.
  • Fatigue rated to 1.5 times the WLL.
  • All YOKE Lifting points meet or exceed all the requirements of ASME B30.26.

Code“DAB”

8-0573

  • Pivots through 180°.
  • Manufactured from forged alloy steel, quenched and tempered.
  • Manufactured and tested in accordance with EN1677-1.
  • Load rated parts are 100% magnaflux crack detected.
  • Individual forged parts are traceable to Test Certification.
  • Proof tested to 2.5 times the WLL.
  • Fatigue rated to 1.5 times the WLL.
  • All YOKE Lifting points meet or exceed all the requirements of ASME B30.26.
  • WLL forged onto each product for quick and easy identification.
  • Lugs designed to assist the welding process.

8-204 UNC Thread

  • Rotates through 360° and pivot 180°, rated at 100% at 90°angle.
  • Manufactured from forged alloy steel, quenched and tempered.
  • Manufactured and tested in accordance with EN1677-1.
  • Load rated parts are 100% magnaflux crack detected.
  • Individual forged parts and cap screw are traceable to Test Certification.
  • Bolt are UNC thread (ASME/ ANSI B18.31M).
  • Proof tested to 2.5 times the WLL.
  • Fatigue rated to 1.5 times the WLL.
  • All YOKE Lifting points meet or exceed all the requirements of ASME B30.26.
  • Quick and simple assembly, just a tapped hole is required.

8-203 Metric Thread

  • Rotates through 360° and pivot 180°, rated at 100% at 90°angle.
  • Manufactured from forged alloy steel, quenched and tempered.
  • Manufactured and tested in accordance with EN1677-1.
  • Load rated parts are 100% magnaflux crack detected.
  • Individual forged parts and cap screw are traceable to Test Certification.
  • Bolt are Metric thread (ASME / ANSI B18.3.1M).
  • Proof tested to 2.5 times the WLL.
  • Fatigue rated to 1.5 times the WLL.
  • All YOKE Lifting points meet or exceed all the requirements of ASME B30.26.
  • Quick and simple assembly, just a tapped hole is required

8-272 UNC Thread

  • Pivots to 230°, rotates through 360° due to its unique ball bearing design. Design factor 4:1 in all directions.
  • Manufactured from forged alloy steel, quenched and tempered.
  • Manufactured and tested in accordance with EN1677-1.
  • Load rated parts are 100% magnaflux crack detected.
  • Individual forged parts and batch code links to Test Certificate sheet.
  • Bolt are UNC thread (ASME / ANSI B18.3.1M).
  • Proof tested to 2.5 times the WLL.
  • Fatigue rated to 1.5 times the WLL.
  • All YOKE Lifting points meet or exceed all the requirements of ASME B30.26.
  • Easy to attach or dismantle due to the forged hexagon shaped body of the Swivel Point.
  • Maximum WLL in axial direction when load ring is aligned.
  • Capable of rotating under load. Do not turn continuously in 90 degree direction at full load.

8-S292 UNC Thread

  • Rotates through 360° adjustable in the direction of the load.
  • Manufactured from stainless steel. Captive bolt with high WLL.
  • Manufactured and tested in accordance with DGUV GS-OA 15-04.
  • Individual forged parts and cap screw are traceable to Test Certification.
  • Bolts are UNC thread (ASME / ANSI B18.3.1M).
  • Proof tested to 2.5 times the WLL.
  • Fatigue rated to 1.5 times the WLL.
  • All YOKE Lifting points meet or exceed all the requirements of ASME B30.26.
  • Quick and simple assembly, just a tapped hole is required.
  • Used in different applications such as chemical oil coal industries, food processing, clean room and precision instrument.

8-S291 Metric Thread

  • Rotates through 360° adjustable in the direction of the load.
  • Manufactured from stainless steel. Captive bolt with high WLL.
  • Manufactured and tested in accordance with DGUV GS-OA 15-04.
  • Individual forged parts and cap screw are traceable to Test Certification.
  • Bolts are Metric thread (ASME / ANSI B18.3.1M).
  • Proof tested to 2.5 times the WLL.
  • Fatigue rated to 1.5 times the WLL.
  • All YOKE Lifting points meet or exceed all the requirements of ASME B30.26.
  • Quick and simple assembly, just a tapped hole is required.
  • Used in different applications such as chemical oil coal industries, food processing, clean room and precision instrument.

8-292K UNC Thread

  • Rotates through 360° adjustable in the direction of the load.
  • Manufactured from alloy steel, quenched and tempered. Captive bolt with high WLL.
  • Manufactured and tested in accordance with EN1677-1.
  • Load rated parts are 100% magnaflux crack detected.
  • Individual forged parts and cap screw are traceable to Test Certification.
  • Bolts are UNC thread (ASME / ANSI B18.3.1M), specification is grade 10.9 alloy socket head screw per DIN EN ISO 4762.
  • Proof tested to 2.5 times the WLL.
  • Fatigue rated to 1.5 times the WLL.
  • All YOKE Lifting points meet or exceed all the requirements of ASME B30.26.
  • Quick and simple assembly, just a tapped hole is required.

8-291K Metric Thread

  • Rotates through 360° adjustable in the direction of the load.
  • Manufactured from alloy steel, quenched and tempered. Captive bolt with high WLL.
  • Manufactured and tested in accordance with EN1677-1.
  • Load rated parts are 100% magnaflux crack detected.
  • Individual forged parts and cap screw are traceable to Test Certification.
  • Bolts are Metric thread (ASME / ANSI B18.3.1M), specification is grade 10.9 alloy socket head screw per DIN EN ISO 4762.
  • Proof tested to 2.5 times the WLL.
  • Fatigue rated to 1.5 times the WLL.
  • All YOKE Lifting points meet or exceed all the requirements of ASME B30.26.
  • Quick and simple assembly, just a tapped hole is required.

8-231L Metric Thread

  • Rotates through 360° and pivot 180°, and simultaneously allows lifting from any direction.
  • Manufactured from forged alloy steel, quenched and tempered.
  • Manufactured and tested in accordance with EN1677-1.
  • Load rated parts are 100% magnaflux crack detected.
  • Individual forged parts and cap screw are traceable to Test Certification.
  • Bolt are Metric thread (ASME / ANSI B18.3.1M).
  • Proof tested to 2.5 times the WLL.
  • Fatigue rated to 1.5 times the WLL.
  • All YOKE Lifting points meet or exceed all the requirements of ASME B30.26.
  • Quick and simple assembly, just a tapped hole is required.

8-232 UNC Thread

  • Rotates through 360° and pivot 180°, and simultaneously allows lifting from any direction.
  • Manufactured from forged alloy steel, quenched and tempered.
  • Manufactured and tested in accordance with EN1677-1.
  • Load rated parts are 100% magnaflux crack detected.
  • Individual forged parts and cap screw are traceable to Test Certification.
  • Bolt are UNC thread (ASME / ANSI B18.3.1M).
  • Proof tested to 2.5 times the WLL.
  • Fatigue rated to 1.5 times the WLL.
  • All YOKE Lifting points meet or exceed all the requirements of ASME B30.26.
  • Quick and simple assembly, just a tapped hole is required.

8-231 Metric Thread

  • Rotates through 360° and pivot 180°, and simultaneously allows lifting from any direction.
  • Manufactured from forged alloy steel, quenched and tempered.
  • Manufactured and tested in accordance with EN1677-1.Load rated parts are 100% magnaflux crack detected.
  • Individual forged parts and cap screw are traceable to Test Certification.
  • Bolt are Metric thread (ASME / ANSI B18.3.1M).
  • Proof tested to 2.5 times the WLL.
  • Fatigue rated to 1.5 times the WLL.
  • All YOKE Lifting points meet or exceed all the requirements of ASME B30.26.
  • Quick and simple assembly, just a tapped hole is required.

8-211L Metric Thread

  • Rotates through 360° and pivot 90°.
  • Manufactured from alloy steel, quenched and tempered.
  • Manufactured and tested in accordance with EN1677-1.
  • Load rated parts are 100% magnaflux crack detected.
  • Individual forged parts and cap screw are traceable to Test Certification.
  • Bolts are Metric thread (ASME / ANSI B18.3.1M), specification is grade 12.9 alloy socket head screw per DIN EN ISO 4762.
  • Proof tested to 2.5 times the WLL.
  • Fatigue rated to 1.5 times the WLL.
  • All YOKE Lifting points meet or exceed all the requirements of ASME B30.26.
  • Quick and simple assembly, just a tapped hole is required.

8-212 UNC Thread

  • Rotates through 360° and pivot 90°.
  • Manufactured from alloy steel, quenched and tempered.
  • Manufactured and tested in accordance with EN1677-1.
  • Load rated parts are 100% magnaflux crack detected.
  • Individual forged parts and cap screw are traceable to Test Certification.
  • Bolts are UNC thread (ASME / ANSI B18.3.1M), specification is grade 12.9 alloy socket head screw per DIN EN ISO 4762.
  • Proof tested to 2.5 times the WLL.
  • Fatigue rated to 1.5 times the WLL.
  • All YOKE Lifting points meet or exceed all the requirements of ASME B30.26.
  • Quick and simple assembly, just a tapped hole is required.

8-211 Metric Thread

  • Rotates through 360° and pivot 90°.
  • Manufactured from alloy steel, quenched and tempered.
  • Manufactured and tested in accordance with EN1677-1.
  • Certified by DGUV GS-OA 15-04.
  • Load rated parts are 100% magnaflux crack detected.
  • Individual forged parts and cap screw are traceable to Test Certification.
  • Bolts are Metric thread (ASME / ANSI B18.3.1M), specification isgrade 12.9 alloy socket head screw per DIN EN ISO 4762.
  • Proof tested to 2.5 times the WLL.
  • Fatigue rated to 1.5 times the WLL.
  • All YOKE Lifting points meet or exceed all the requirements ofASME B30.26.
  • Quick and simple assembly, just a tapped hole is required

Leaf Chain

Renold’s range of leaf chain for materials handling applications is used worldwide for straddle carriers, forklift trucks and on major civil engineering works such as flood defence barriers.

Features:
>High Fatigue strength
>Long Service Life
>Maximum Resistance to wear
>Compact Design.

Roller Chain

Renold roller chain comes with all the security and performance that you want to keep your chain drives in great shape. All these great features make Renold the first choice for industry.

Features:
>Solid roller and solid bush.
>End-softened pins make it easy to disassemble this chain.
>Look for the round or “spin” riveting for the sign of a Renold chain.
>The high waist plate shape with a high waist gives better stress distribution.
>Engineered for the best fatigue resistance you can get.
>Delivers wear resistance that surpasses anything produced elsewhere.
>Components manufactured to the highest specifications for unbeatable accuracy.

Conveyor Chain

Serving industries all over the world, Renold’s conveyor chain expertise is based on design experience, flexible manufacturing techniques and the ability to adapt to a particular customer’s requirements to produce the right result.

The precision conveyor chain, like transmission chain, consists of a series of journal bearings held in precise relationship to each other by constraining link plates.

Each bearing consists of a bearing pin and bush on which the chain roller revolves. The bearing pin and bush are case-hardened to allow articulation under high pressures, and to contend with the load carrying pressure and gearing action imparted via the chain rollers.

There is, for each strength of conveyor chain, a range of pitches; the minimum pitch being governed by the need for adequate wheel tooth strength; the maximum pitch being normally dictated by plate and general chain rigidity. When required, the normal maximum pitch can be exceeded by the use of strengthening bushes between the link plates, and suitable gaps to clear the bushes must be provided in the wheel teeth.

Chain Shortner

Strong, Reliable and Easy.

Features:
>Working Load Limit – 1.12T to 31.5T.
>With Pin Coupling.
>Alloy Steel – Quenched and Tampered.
>Colour Painted Finish.
>100% proof tested.

Connecting Link

Features:
>Working Load Limit – 1.5T to 31.5T.
>Suitable for use with both Grade 80 and Grade 100 chain.
>100% proof tested.
>Locking system that provides for simple assembly and disassembly – no special tools needed.

Master Link Assembly

Features:
>Working Load Limit – 2.36t to 200t.
>Alloy Steel – Quenched and Tempered.
>100% proof tested.

Master Link

Features:
>Working Load Limit – 1.6t to 140t.
>Alloy Steel – Quenched and Tempered.
>100% proff tested.

Foundry Hook

Features :
>Working load limits up to 31.5 tons.
>Forged Alloy Steel – Quenched and Tempered.
>Fatigue rated.

Swivel Self Locking Eye Hook

Swivel Self Locking Eye Hook’s large swivel eye makes assembly to fibre / wire rope slings (with thimbles) easier.

Self Locking Eye Hook

Self Locking Eye Hook comes with a slef-locking lock latch. The self-locking lock latch is very useful and it improves the safety of the product.

Clevis Hook

Thiele Clevis Hook are well designed eye hooks for your use.

Grade 80/100 Chain Slings

Features:
>High grade alloy steel are chosen carefuly.
>Strict control of material acceptance and Processing is carried out by skilled personnel.
>The Chains have a high capacity to absorb shock loading.
>High level of Quality and Reliablity.
>Electronically controlled chain machines have been specially built and developed to provide advanced manufacturing process.  They will give a minimum extension of 20% under a destruction test before fracture occurs.

H 100 Spark Resistant Series

Features :
>Capacity : 05.t ~ 20 ton.
>Hand chain hoists, push & geared trolleys.
>II 2 GD c II B T105° C.
>Adheres to the Council Directive and Standards in the EU for explosion proof manual chain hoists. 94/9/EC : >ATEXEN1127-1 :2008, EN13463-1 : 2009, EN13463-5 : 2003.
>Push & geared trolley dimensions are identical to the P and G series of trolleys, see catalog page 21.
>Extremely wear resistant.
>Load chain, hooks, and braking parts have a safety factor of 4+ times. 0.5t ~ 1t units have a safety factor of 5+ times.
>Durable powder coat finish.

Elephant C 21 Series Manual Hoist

Elephant C 21 Model – Made in Japan

We offer Grade 100 – Galvanised Load Chain standard for all chain blocks. Specially designed and manufactured by Elephant in Japan.

Only Original Elephant JIS Grade V – Long Life Load Chains are suitable for this manual hoist.

Features:

  • Drop forged, properly normalised hooks
  • Tough framing.
  • Strong, least corrosive.
  • Electrostatic powder painting.
  • Safe, dry, long-lasting friction disc.
  • Free from oil permeation.
  • Very light and compact body, (9.2kg 1ton).
  • Easy to carry.
  • Elephant’s original long-life chain.
  • Best wear resistance on record for manual hoist.

We can provide Over Load Limit Device as an option on request.

Elephant’s high-tech load chains are approved by DIN 5684, one of the world’s strictest standards. This is the special heat-treated load chain of Grade V (100 kgf /mm2) whose tensile strength far surpasses JIS Grade V.

Features :

ec_c21_3

Specifications

C21-0.5 Dimensions

Figure of C21-0.5 dimensions
( A : Headroom )

( mm )

Model
Amin
B
C
D
E
C21-0.5
275
130
53.5
76.5
121
Model
F
G
H
I
N
C21-0.5
30
36
17
13
24
1 ) Dimension N is applicable when safety latch is opened.
*All specifications herein are subject to change without prior notice.

C21-0.5 Specifications

Model
C21-0.5
Capacity ( ton )
0.5
Standard lift ( m )
2.5
Manufacturer’s test load ( ton )
0.75
Headroom ( mm )
275
Length of load chain lifted
by pulling hand chain 1m ( mm )
33
Hand effort to lift full working load ( N ) ( kg )
255 ( 26 )
Load chain
Dia. x pitch ( mm ) x ( mm )
4.3 X 12
No. of falls
1
Grade of chain
V
Hand chain
Dia. x pitch ( mm ) x ( mm )
4.5 X 23
Net weight ( kg )
6.2
*All specifications herein are subject to change without prior notice.
Catalog
Instruction manual

C21-1 Dimensions

Figure of C21-1 dimensions
( A : Headroom )

( mm )

Model
Amin
B
C
D
E
C21-1
310
143
61
82
148
Model
F
G
H
I
N
C21-1
34
43
22
16
29
1 ) Dimension N is applicable when safety latch is opened.
*All specifications herein are subject to change without prior notice.

C21-1 Specifications

Model
C21-1
Capacity ( ton )
1
Standard lift ( m )
2.5
Manufacturer’s test load ( ton )
1.5
Headroom ( mm )
310
Length of load chain lifted
by pulling hand chain 1m ( mm )
21
Hand effort to lift full working load ( N ) ( kg )
314 ( 32 )
Load chain
Dia. x pitch ( mm ) x ( mm )
5.6 X 17
No. of falls
1
Grade of chain
V
Hand chain
Dia. x pitch ( mm ) x ( mm )
4.5 X 23
Net weight ( kg )
9.2
*All specifications herein are subject to change without prior notice.
Catalog
Instruction manual

C21-1.5 Dimensions

Figure of C21-1.5 dimensions
( A : Headroom )

( mm )

Model
Amin
B
C
D
E
C21-1.5
340
152
68
84
168
Model
F
G
H
I
N
C21-1.5
35
43
26
21
30
1 ) Dimension N is applicable when safety latch is opened.
*All specifications herein are subject to change without prior notice.

C21-1.5 Specifications

Model
C21-1.5
Capacity ( ton )
1.5
Standard lift ( m )
2.5
Manufacturer’s test load ( ton )
2.25
Headroom ( mm )
340
Length of load chain lifted
by pulling hand chain 1m ( mm )
15
Hand effort to lift full working load ( N ) ( kg )
324 ( 33 )
Load chain
Dia. x pitch ( mm ) x ( mm )
6.5 X 19
No. of falls
1
Grade of chain
V
Hand chain
Dia. x pitch ( mm ) x ( mm )
4.5 X 23
Net weight ( kg )
11.7
*All specifications herein are subject to change without prior notice.
Catalog
Instruction manual

C21-2 Dimensions

Figure of C21-2 dimensions
( A : Headroom )

( mm )

Model
Amin
B
C
D
E
C21-2
380
164
75
89
193
Model
F
G
H
I
N
C21-2
43
53
29
22
34
1 ) Dimension N is applicable when safety latch is opened.
*All specifications herein are subject to change without prior notice.

C21-2 Specifications

Model
C21-2
Capacity ( ton )
2
Standard lift ( m )
3
Manufacturer’s test load ( ton )
3.0
Headroom ( mm )
380
Length of load chain lifted
by pulling hand chain 1m ( mm )
11
Hand effort to lift full working load ( N ) ( kg )
324 ( 33 )
Load chain
Dia. x pitch ( mm ) x ( mm )
7.5 X 21
No. of falls
1
Grade of chain
V
Hand chain
Dia. x pitch ( mm ) x ( mm )
4.5 X 23
Net weight ( kg )
16.9
*All specifications herein are subject to change without prior notice.
Catalog
Instruction manual

C21-3 Dimensions

Figure of C21-3 dimensions
( A : Headroom )

( mm )

Model
Amin
B
C
D
E
C21-3
480
152
68
84
209
Model
F
G
H
I
N
C21-3
43
53
35
28
36
1 ) Dimension N is applicable when safety latch is opened.
*All specifications herein are subject to change without prior notice.

C21-3 Specifications

Model
C21-3
Capacity ( ton )
3
Standard lift ( m )
3
Manufacturer’s test load ( ton )
4.5
Headroom ( mm )
480
Length of load chain lifted
by pulling hand chain 1m ( mm )
7.6
Hand effort to lift full working load ( N ) ( kg )
373 ( 38 )
Load chain
Dia. x pitch ( mm ) x ( mm )
6.5 X 19
No. of falls
2
Grade of chain
V
Hand chain
Dia. x pitch ( mm ) x ( mm )
4.5 X 23
Net weight ( kg )
19.1
*All specifications herein are subject to change without prior notice.
Catalog
Instruction manual

C21-5 Dimensions

Figure of C21-5 dimensions
( A : Headroom )

( mm )

Model
Amin
B
C
D
E
C21-5
555
164
75
89
297
Model
F
G
H
I
N
C21-5
58
70
46
34
45
1 ) Dimension N is applicable when safety latch is opened.
*All specifications herein are subject to change without prior notice.

C21-5 Specifications

Model
C21-5
Capacity ( ton )
5
Standard lift ( m )
3
Manufacturer’s test load ( ton )
7.5
Headroom ( mm )
555
Length of load chain lifted
by pulling hand chain 1m ( mm )
3.7
Hand effort to lift full working load ( N ) ( kg )
334 ( 34 )
Load chain
Dia. x pitch ( mm ) x ( mm )
7.5 X 21
No. of falls
3
Grade of chain
V
Hand chain
Dia. x pitch ( mm ) x ( mm )
4.5 X 23
Net weight ( kg )
34.7
*All specifications herein are subject to change without prior notice.

DA/DB Series

The DA/DB series hoist features a newly developed motor for severe conditions, which allows it to operate continuously for long periods of time with frequent starts within an hour cycle. These lifting speeds were engineered to be as fast as possible to ensure efficiency.

Features :
>Highly durable load chain.
>Safe DOUBLE BRAKE design.
>DC brake and motor with low power consumption.
>A safer chain guide with our unique design.
>Reliable double-action limit switch.
>Negative phase contactor and a highly efficient magnetic contact with a mechanical & electrical interlock.
>Durable chain container.

FA/FB/SA Series

Our new Torcon overload protection device is a slip clutch style. In the event of an overload, the device actuates and prevents the hoist from continuing to lift. This mechanism protects the hoist from damage.

Features :
>Capacity: 1/2 ton to 5 ton.
>MAS series motorized trolley, three phase, single speed, slower traversing speed, for combination with the FA series electric chain hoists.
>MAF series motorized trolley, three phase, single speed, faster traversing speed, for combination with the FA series electric chain hoists.
>MB series motorized trolley, three phase, dual speed, for combination with the FA series electric chain hoists.
>Trolleys come with pivoting adapter for hook to hook type suspension or lug type suspension.
>Reliable Electro-Magnetic DC Brake.
>Chain Bucket Hard plastic.
>Limit switch Standard feature.

Wire Rope Slings

Wire Rope Slings are strong, durable and abrasion resistant. Wire Rope Slings are used to harness various kinds of goods. They offer a strong, dependable and economical option for most lifting applications. The popularity of Wire Rope Slings is enhanced by the number of configurations possible and available to support a huge range of applications.

Slings Sizes – 8 mm to 96 mm

Capacity – 0.5 Ton to 100 Tons

Single Leg / Multi Leg / Endless

We offer Grade 80 and Grade 100 accessories as options

We offer Mechanical Splicing and Hand Splicing Slings as per Indian Standards

Wire Rope Used for Sling making – Usha Martin / Bridon Bekeart / Safelift

Link Chain

Safelift’s Link chains are Grade 80 Alloy Steel Chains which was designed primarily to achieve the consistent high level of quality and reliability of Safelift Products.

Features:
>High grade alloy steel chain are chosen carefully.
>Strict control of material acceptance and processing is carried out by skilled personnel.
>They are produced so that they will give a minimum extension of 20% under a destruction test before fracture   occurs.
>The chains are ensured to have a high capacity to aborb shock loading.

Cargo Lashing Ratchet

Safelift lashings are the modern, light weight and throughly reliable method of securing all types of load across an entire spectrum of requirements.

Ratchet lashing are used to fix the cargo while transporting, shifting or moving storage. It being more secure, reliable and much lighter in weight as compared to chains, wire and jute ropes which were traditionally used.

Features :
>Load restraint using a tensioning device(Ratchet).
>Effective and safe control of load being tied down. No damage to the load being tied down.
>Extrmely quick and efficient tie down and release of load thus save time.

Chain Shortner

Strong, Reliable and Easy to use Safelift’s Chain Shortner. Designed to withstand heavy duty in shipping and industrial applications.

Features:
>Working Load Limit – 1.12T to 15T.
>Alloy Steel – Quenched and Tampered.
>Colour Painted Finish.
>100% proof tested.

Connecting Link

Features:
>Working Load Limit – 1.12T to 31.5T.
>Suitable for use with both Grade 80 and Grade 100 chain.
>100% proof tested.
>Locking system that provides for simple assembly and disassembly – no special tools needed.

Master Link Assembly

Features:
>Working Load Limit – 2.36t to 63t.
>Alloy Steel – Quenched and Tempered.
>100% proff tested.

Master Link

Features:
>Working Load Limit – 1.6t to 63t.
>Alloy Steel – Quenched and Tempered.
>100% proff tested.

Grab Hook

Safelift’s Grab Hook are an ideal choice for marine and industrial applications.

Features:
>Working Load Limit – 1.12t to 31.5t.
>Forged Alloy Steel – Quenched and Tempered.
>Individually Proof Tested to 2-1/2 times the Working Load Limit with certification.
>Suitable for use with Grade 100 and Grade 80 chain.
>100% proof tested.

Foundry Hook

Features :
>Working load limits up to 31.5 tons.
>Forged Alloy Steel – Quenched and Tempered.
>Fatigue rated.

Swivel Self Locking Eye Hook

Swivel Self Locking Eye Hook’s large swivel eye makes assembly to fibre / wire rope slings (with thimbles) easier.

Self Locking Eye Hook

Self Locking Eye Hook comes with a slef-locking lock latch. The self-locking lock latch is very useful and it improves the safety of the product.

Clevis Hook

Safelift Clevis Hook are 100% proof tested and can be used with both grade 80 & 100 chains.

To see more details download the PDF File.

Eye Hook

Safelift Eye Hooks are an excellent choice for eye hooks. These hooks are designed for overhead lifting.

Features :
100% proof tested.
Fatigue Rated.

D-Shackle Screw Pin

Screw Pin type anchor shackles with thin head bolt-nut with cotter pin. Meets the requirements of Federal Specification.

Features :
Capacities : 1 to 55 tons.
Forged – Quenched and Tempered, with alloy pins.
Working Load Limit permanently shown on every shackle.
Lock for the yellow pin, the mark of the genuine safelift quality.
Shackles can finished be proof tested with certificates, Charges for proof testing & certification available when requested at the time of order.
Shackles are galvanized

D-Shackle Nut Bolt

Screw Pin type anchor shackles with thin head bolt-nut with cotter pin. Meets the requirements of Federal Specification.

Features :
Capacities : 1 to 55 tons.
Forged – Quenched and Tempered, with alloy pins.
Working Load Limit permanently shown on every shackle.
Lock for the yellow pin, the mark of the genuine safelift quality.
Shackles can finished be proof tested with certificates, Charges for proof testing & certification available when requested at the time of order.
Shackles are galvanized

Bow Shackle Screw Pin

Bolt type anchor shackles with thin head bolt-nut with cotter pin. Meets the requirements of Federal Specification.

Features :
Capacities : 1 to 55 tons.
Forged – Quenched and Tempered, with alloy pins.
Working Load Limit permanently shown on every shackle.
Lock for the yellow pin, the mark of the genuine safelift quality.
Shackles can finished be proof tested with certificates, Charges for proof testing & certification available when requested at the time of order.
Shackles are galvanized

Bow Shackle Nut Bolt

Features :
Capacities : 1 to 55 tons.
Forged – Quenched and Tempered, with alloy pins.
Working Load Limit permanently shown on every shackle.
Lock for the yellow pin, the mark of the genuine safelift quality.
Shackles can finished be proof tested with certificates, Charges for proof testing & certification available when requested at the time of order.
Shackles are galvanized

Electric Pallet Truck

Safelift left no detail uncovered in building the electric pallet truck. Designed for durability, uptime and operator control, this electric pallet truck is the walkie pallet truck that takes on the toughest demands.

Features:
Capacity: upto 2000 Kgs.

Universal Plate Lifting Clamps

Features:
Load Range: 1 ton to 10 tons.
It is applicable in lifting steel plates and many more objects.
One piece of clamp is used for testing but one or two pieces are recommended for lifting operation.
Tested load is 2 times of working load.
The handle is facility, the way of hoistin is broader.

Horizontal Plate Lifting Clamps

Features:
>Load Range: 1 ton to 6 tons.
>Safelift’s Horizontal Plate Lifting Clamp is made of Low Carbon alloy Steel.
>Two pieces of clamp is used for testing but two or four pieces are recommended for lifting operation.
>Durable enduring, easy to operate.

Hand Pallet Truck

Safelift’s rugget yet light-weight hand pallet truck, designed to meet and exceed the demands of your toughest workplace environments.

Features:
>Capacity: upto 2500 Kgs.
>Large diameter hand grip with curvilinear handle design.
>Fingertip control of all functions.
>Lorem ipsum.

SL-50/35S Series

Safelift’s hydraulic Lifting Table are one of the most popular lifting table as they fit wide range of applications.

Features:
>Capacity: upto 500 Kgs .

Hand Stacker

Suitable for light stacking applications in confined areas and stores, the Safelift hand stacker has load capacities up to 2000 Kgs.

Features:
>Capacity: upto 2000 Kgs.

Grade 80 Chain Slings

Features:
>High grade alloy steel are chosen carefuly.
>Strict control of material acceptance and Processing is carried out by skilled personnel.
>The Chains have a high capacity to absorb shock loading.
>High level of Quality and Reliablity.
>Electronically controlled chain machines have been specially built and developed to provide advanced manufacturing process.  They will give a minimum extension of 20% under a destruction test before fracture occurs.

Polyester Round Slings

Safelift Round Sling – Made in India

Safety Factor 7:1 / 5:1

Capacity – 1 Ton to 200 Ton

Single Leg and Multi leg option available

Fittings and Sling accessories available for customisation of products

Products are tested and manufacturing as per International Standards

Round Polyester Sling Safelift

Duplex Polyester Webbing Slings

Safelift flat webbing slings are manufactured from high tensity, 100% polyester yarn. Duplex slings are stitched with two layers of webbing throughout of their length. Sling ends are terminated either in reinforced loops or any combination of metal end fittings. manufacturer’s test certificate is provided for safe work load along with the slings.

Safety Factor : 6:1 – Made in India

Safelift Polyester Slings are now ISI marked and meet International Manufacturing Standards

The slings are of three types, namely duplex sling with metal end fittings and endless sling. They normally lift loads with the sling reeved around the load (Choke Hitch), or on two parts of the slings (Basket Hitch). They are tested in straight pull.

Duplex Polyester Sling Safelift

Magnetic Lifter

The magnetic lifter can be in variety industries for the transportation and lifting of steel, engine parts, semi manufactured goods and moulds, due to its magnetic.

Larger sizes available, output up to 6000Kgs.

Features:
>The magnetic lifter’s pulling force is 3.5 times greater than rated lifting capability.
>Light weight, range from 10-250Kgs.
>No Electricity is needed to operate the magnetic lifter, one operated there is less than 1% residual magnetism.

Electric Trolley

The Safelift Electric Trolley was designed to be utilized with a lug mounted Electric Chain Hoist where versatility and strength are key components.

Features:
>Capacity: 0.5t – 10t.
>Optional Trolley guards.
>Fits wide range of beam sizes for maximum versatility.
>Minimum radius trun range from 0.8m to 2.5m.

Geared Trolley

Hand geared trolleys are an excellent option when accurate load spotting is a must.

Features:
>Capacity: 0.5t – 20t.
>Anti corrosive powder coated finish.
>Adjustable to various rail widths.
>Use of high quality bearings.

Electric Wire Rope Hoist

Features:
>The hoist detects the amount of lining abrasion. The brake is equipped with as automatic adjusting device to apply brake torque in proportion to the amount of lining abrasion.
>The double braking system consists of the main brake and the auxiliary brake unit.
>The hoist motor automatically stops when sensing the heat of the motor coil in order to protect the motor from burning damage caused by heat due to overwork.
>It boasts high performance for use in rugged jobs such as general production in factories, mining, railroads and warehouses.

Electric Chain Hoist

Safelift Hoist Catalog 2020

Heavy Duty Chain Hoist for Industrial Applications

Capacity – 300 kgs to 20 Tons

3 Phase – 50 hz – 380v to 430v

1 year warranty against manufacturing defect

Excellent Performance with long life and low maintenance.

Robust and compact build to suit a variety of tough industrial applications.

Pulling And Lifting Machine

Pulling Lifting Safelift Catalog 2020

Multipurpose, Portable, Hand operated Pulling & Lifting Machine, supplied complete with telescopic, operated handle and standard length of steel core wire-rope fitted with hook or shackle at one end and fused and tapered at the other end.

Features:
Capacity: 1600kgs to  8000Kgs
Aluminium Casting light weight body makes our product easy to carry than before

Excellent Built Quality, Superior design for easy to install wire rope and easy of use.

Supplied with 10 Meter Wire Rope as standard.

We can also offer 20 meter or 30 meter rope length as an option on request.

Ratchet Lever Hoist

The Safelift’s Ratchet Lever Hoist is a Manual Chain Hoists designed for heavy duty use yet light-weight. It has lot of applications in different Industries. You can use it to lift, Lower, Fasten and Pull materials.

Features:
Capacity: 0.25 Ton – 9 Ton
German design and technology.
Safety latch on hooks..
Grade 80 alloy Steel Load chain for strength and wear resistance.
Light weight and compact.
Superior Asbestos free Break.
Low operation effort.
Anti corrosive powder coated finish.

Saif-T Series

The Safelift’s Saif-T Series of Manual Chain Hoists are designed for heavy duty use for all Industrial applications. It is designed keeping in mind to be reliable, durable and withstanding your Heavy Industrial needs.

Features:

  • Capacity: 1t – 20t.
  • Surface hardended gears.
  • Anti corrosive powder coated finish.
  • Grade 80 alloy Steel Load chain for strength and wear resistance.
  • Minimum maintenance for reduced downtime.
  • Smooth passage of load chain and smooth hand chain operation.
  • Double ratchet pawl for enhanced safety.
  • 1 year warranty against manufacturing defects.

G100 Connecting Link,

Special pin and sleeve designed for more often re-use purpose ? Design factor 4:1 proof tested and certified.
